Vortex Diamondback 4-12x40 Product description

The Diamondback with the most magnification of the range, the 4-12x40 is an impressive tool for medium to long range shooting. Initially meant for smaller calibers, all durability tests showed that it will withstand anything, even the largest calibers, as well as all environmental impacts it might encounter out there. The lenses on the scope are also coated for protection as well as for anti-reflection purposes, and are large enough to let through comfortable amounts of light. The image will always be sharp and crisp with the high quality lenses and the adjustable, fast focus eyepiece. The SFP set reticle will retain its excellent size at all magnifications, making fast and accurately placed shoots easy at any magnification, from medium or short range with the 4x and up to the longer ranges with the maximum, 12x magnification while using the Dead-hold BDC reticle.

Advanced Features

The single piece, aircraft aluminum tube will withstand the kick of any caliber, and is made for durability. It’s hard anodized for protection against the elements. The anodizing is made in matte finish to prevent light reflection for better concealment of the shooter. The lenses are multi-coated to prevent scratches, fingerprints and stains and the coating will repel water and grease drops as well. The whole scope is sealed and watertight, and the Argon purging of the interior will prevent any fogging on the internal lenses.

Reticle Illumination

The Diamondback series of scopes does not come with reticle illumination. They are made for hunting and shooting at daylight and the reticle options are chosen with that in mind. The scopes are made with rather large exit lenses in regards to the magnification options, which will let in enough light for comfortable shooting at any distance with the right scope option.

Configuration Options

This turrets come with caps for extra protection while on the move. They are easily re-indexed and resettable. The parallax is fixed, at 91 meters.

The scope comes in two reticle variants, wither the crude yet simple and fine V-Plex cross-hairs or the plain Dead-hold BDC that comes with a nice BDC system. In either case, the turrets have ¼ MOA adjustment graduation and have an impressive 60 MOA travel with both windage and elevation.

Warranty Information

All Vortex scopes come with a VIP warranty, which means that if anything goes wrong the Company will cover your scope. Your scope will be either repaired or replaced if it becomes defective, without any costs for you. You can also read more about our warranty policy here.

Mounting Options

The Vortex Diamondback 4-12x40 has a 25,4mm central tube and need appropriate rings for mounting.

General properties

Manufacturer	Vortex
Riflescopes series	Vortex Diamondback
Made in	Philippines
Warranty	-
SKU	DBK-04-BDCc

Optical properties

Variable magnification	Yes
Minimal magnification.	4.00 x
Maximum magnification.	12.00 x
Lens diameter.	40.00 mm
Min. exit pupil.	3.30 mm
Max. exit pupil.	6.80 mm
Min. field of view.	3.80 m/100m
Max. field of view.	10.80 m/100m
Min. eye relief.	79.00 mm
Max. eye relief.	86.00 mm
Fast focus eyepiece	Yes

Turret properties

Adjustment per click	7mm/100m - 1/4MOA
Turret Type	Capped
Zero Stop	No
Nr. Turret Turns	MT - Multi Turn
Elevation (mrad).	17.44 mrad
Elevation (MOA).	60.00 MOA
Windage (mrad).	17.44 mrad
Windage (MOA).	60.00 MOA
Elevation Per Turn	15 MOA - 43.5 cm

Reticle properties

Reticle position	2. focal plane - SFP
Reticle illumination	No
Illumination color	-
Daytime-usable illumination	No
Auto Turn-Off	No

Parallax properties

Parallax setting	90m
Parallax adjustment	No

Physical properties

Length.	305.00 mm
Weight.	422.00 g
Filled with	Argon
Lens coating	Multicoated
Tube diameter	25.4 mm
Mount rail type	No
Mount length.	142.00 mm
Objective diameter	45.7 mm
Eyepiece diameter	40.6 mm

Special features

Waterproof	Yes
Fogproof	Yes
Shockproof	Yes
Special features	Fast focus, Fogproof, Fully multicoated, Shockproof, Variable, Waterproof
Built-in rangefinder	No
