Rudolph AR 1-8x24mm Product description

Rudolph AR 1-8x24mm

General properties

Manufacturer	Rudolph Optics
Riflescopes series	Rudolph Optics AR
Made in	China
Warranty	10 years
SKU	AR-010824-AR1

Optical properties

Variable magnification	Yes
Minimal magnification.	1.00 x
Maximum magnification.	8.00 x
Lens diameter.	24.00 mm
Min. exit pupil.	0.12 inch (3.00 mm)
Max. exit pupil.	0.94 inch (24.00 mm)
Min. field of view.	13.05 feet/100yards (4.35 m/100m)
Max. field of view.	96.00 feet/100yards (32.00 m/100m)
Min. eye relief.	3.20 inch (81.28 mm)
Max. eye relief.	3.30 inch (83.82 mm)

Turret properties

Adjustment per click	10mm/100m - 0.10MIL
Turret Type	Tactical - Lockable
Turret locking	Yes
Zero Stop	No
Nr. Turret Turns	ST - Single Turn
Turret rotation direction	CW

Reticle properties

Reticle	AR1 FFP IR
Reticle position	1. focal plane - FFP
Reticle illumination	Yes
Illumination color	Red
Daytime-usable illumination	No
Auto Turn-Off	No

Parallax properties

Parallax setting	91.44 m
Parallax adjustment	No
Parallax adj. range	No

Physical properties

Length.	10.30 inch (261.62 mm)
Weight.	18.88 oz (535.24 g)
Power Supply	CR2032
Filled with	Nitrogen
Lens coating	Fully Multicoated
Tube diameter	30 mm
Mounting rail.	No
Color	Black

Special features

Waterproof	Yes
Fogproof	Yes
Shockproof	Yes
Special features	Fogproof, Shockproof, Waterproof
Built-in rangefinder	No

Most common questions (Q&A)

Need help? Not sure about something? Don't hesitate - ask our community! Our experienced community is here to help you with this question.

Hello! What's the height adjustment range on Rudolph AR 1-8x24mm? I would like to combine it with Spuhr Extended QD mount for Picatinny, 30 mm for .223 shooting and I'm wondering can I pick Spuhr with 6 MIL / 20.6 MOA and those two should work fine. Links to products: https://www.optics-trade.eu/en/spuhr-extended-qd-mount-for-picatinny-30-mm-6-mil-20-6-moa.html https://www.optics-trade.eu/en/rudolph-ar-1-8x24mm.html Best regards Mariusz

by Mariusz

According to the specifications, the riflescope has an adjustment range of 35 milli-radians/120 MOA. If you want to increase the adjustment range then a 20 MOA mount is a way to go otherwise we would recommend you the basic version.
